Tekniset tiedot

Capacity
10–30 washing cycles / h
Washing cabinet dimensions W x L x H
Layout drawing
Water consumption average / wash
30–90 ltr, depending on the washed items
Washing tank
350 ltr, thermally insulated
Prewashing tank
350 ltr
Washing solution
alkaline or acid
Programs
20 modified recipe, available for each washing solution and washable item, also for internal machine wash
Material
Stainless steel
Heating options
steam injector, water-based radiator heating or electrical
-----------------
Electric power supply
steam heating: 50 Hz, 400 V, 19 kW | electric heating: 50 Hz, 400 V, 70 kW
Steam supply (steam heating option)
80–100 kg/h, 0.6–0.9 bar, approx. 45 kW
Water intake (warm tap water)
+50–70 °C, 20–60 ltr/min, 3 bar
Compressed air
6 bar, 20–40 ltr/min
Ventilation
0,4 m³/s
0.2–1.5 %, adjustable from control panel
Detergent concentration
Floor draining
d = 110 mm

Tekninen kuvaus

The MultiWasher MW-3 offers an all-in-one washing solution for various types of production equipment and also works well as a parts washer. Its innovative adapter trolley system allows efficient cleaning of items such as lift trolleys, stackable containers, screen plates, freezing plates, and plastic pallets. Each washing program is tailored to the washed object, ensuring optimal hygiene and minimal resource use. Thanks to its compact design, the MW-3 reduces investment and space requirements. Energy, detergent, and water consumption are carefully optimized, lowering operating costs while supporting environmental responsibility. Additional adapters and programs can be supplied later, making the MW-3 a flexible “turnkey” solution for evolving production needs.

Tuotetiedot

Multiwasher main view

Multiwasher

The MultiWasher MW-3 is a compact and cost-efficient washer designed for multiple types of production equipment like crates, bins, containers, different parts. With interchangeable adapter trolleys and optimized washing programs, it ensures top cleaning results while saving energy, water, and detergent.

Järjestelmä:

Pesujärjestelmät

Kategoria:

Multiwasherit

Teollisuudenalat:

AutoteollisuusLeipomoteollisuusJuomateollisuusKalateollisuusElintarviketeollisuusLogistiikkaLihateollisuus
